DuCaR Atom NGun 40 - Pivot End Gun

2 评论 | 添加你的评论

Water Input

2" Female BSP

Working Pressure

25 - 65 psi

Water Flow

183 - 532 l/min

Shooting Radius

19 - 33 m

Nozzles

14, 16, 18, 20 mm

Body Angle

18°

Weight

2.5 kg

Operation

Full & Part Circle

Material

Cast-Iron, Aluminium, Brass

Made in

Turkey

¥2,790.00

制造商: DuCaR Sprinklers

商品库存单位（SKU）: AtomNGun

库存信息:

有货

Shipping

交货日期 3-5 business days

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

Make Your Sprinkler Set:

DuCaR 2" Wheeled Cart with Extendable Legs [+¥1,860.00]
DuCaR 2" Wheeled Cart with Hose Reel [+¥3,813.00]
DuCaR Quick Coupling 4-legged Stand 2" Inlet [+¥1,720.00]

数量:

+ -

DuCaR Atom NGun 40 - Pivot End Gun

We guarantee 100% satisfaction!

It is designed to be used as END GUN on pivot systems. Highly durable, long range, low body angle impact sprinkler head.

Because of our special design and experiences against swing arm models, it’s a highly efficient end gun for pivot systems.

Thanks to its 18° body angle, it is fully compatible with portable or fixed systems in windy areas and where you need to irrigate at low altitudes.

Technical Specifications

mm	inch	kg/cm²	lbs/inch	m	feet	l/min	m³/h	G.P.M	m²	acre	mm/h
Nozzle Diameter		Pressure		Jet Length		Capacity			Values for a single sprinkler
Nozzle Diameter		Pressure		Jet Length		Capacity			Irrigated Area		Rainfall per hour
14mm	0.55	0.75	29	19.0	62	180	0.8	48	1134	0.28	9.5
14mm	0.55	2	29	21.0	69	195	11.7	52	1385	0.34	8.4
14mm	0.55	2.5	37	22.0	72	232	13.9	61	1520	0.38	9.1
14mm	0.55	3	44	24.5	80	238	14.3	63	1885	0.47	7.6
15.2mm	0.60	2	29	23.0	75	195	11.7	52	1661	0.41	7.0
15.2mm	0.60	2.5	37	24.0	79	217	13.0	57	1809	0.45	7.2
15.2mm	0.60	3	44	26.0	85	238	14.3	63	2123	0.52	6.7
15.2mm	0.60	4	56	27.0	89	277	16.6	73	2289	0.57	7.3
16.5mm	0.65	2	29	23.5	77	247	14.8	65	1734	0.43	8.5
16.5mm	0.65	2.5	37	24.5	80	275	16.5	73	1885	0.47	8.8
16.5mm	0.65	3	44	25.5	84	303	18.2	80	2042	0.50	8.9
16.5mm	0.65	4	56	28.0	92	350	21.0	92	2462	0.61	8.5
17.8mm	0.70	2	29	24.0	79	308	18.5	81	1809	0.45	10.2
17.8mm	0.70	2.5	37	25.5	84	333	20.0	88	2042	0.50	9.8
17.8mm	0.70	3	44	26.0	85	343	20.6	91	2123	0.52	9.7
17.8mm	0.70	4	56	29.0	95	437	26.2	115	2641	0.65	9.9
19.1mm	0.75	2	29	25.0	82	345	20.7	91	1963	0.48	10.5
19.1mm	0.75	2.5	37	26.0	85	275	16.5	73	2123	0.52	7.8
19.1mm	0.75	3	44	26.5	87	378	22.7	100	2205	0.54	10.3
19.1mm	0.75	4	56	30.0	98	437	26.2	115	2826	0.70	9.3
20.3mm	0.80	2.5	37	27.0	89	375	22.5	99	2289	0.57	9.8
20.3mm	0.80	3	44	28.0	92	375	22.5	99	2462	0.61	9.1
20.3mm	0.80	4	56	32.0	105	460	27.6	122	3215	0.79	8.6

DuCaR Atom NGun 40 - Pivot End Gun

We guarantee 100% satisfaction!

It is designed to be used as END GUN on pivot systems. Highly durable, long range, low body angle impact sprinkler head.

Because of our special design and experiences against swing arm models, it’s a highly efficient end gun for pivot systems.

Thanks to its 18° body angle, it is fully compatible with portable or fixed systems in windy areas and where you need to irrigate at low altitudes.

Technical Specifications

mm	inch	kg/cm²	lbs/inch	m	feet	l/min	m³/h	G.P.M	m²	acre	mm/h
Nozzle Diameter		Pressure		Jet Length		Capacity			Values for a single sprinkler
Nozzle Diameter		Pressure		Jet Length		Capacity			Irrigated Area		Rainfall per hour
14mm	0.55	0.75	29	19.0	62	180	0.8	48	1134	0.28	9.5
14mm	0.55	2	29	21.0	69	195	11.7	52	1385	0.34	8.4
14mm	0.55	2.5	37	22.0	72	232	13.9	61	1520	0.38	9.1
14mm	0.55	3	44	24.5	80	238	14.3	63	1885	0.47	7.6
15.2mm	0.60	2	29	23.0	75	195	11.7	52	1661	0.41	7.0
15.2mm	0.60	2.5	37	24.0	79	217	13.0	57	1809	0.45	7.2
15.2mm	0.60	3	44	26.0	85	238	14.3	63	2123	0.52	6.7
15.2mm	0.60	4	56	27.0	89	277	16.6	73	2289	0.57	7.3
16.5mm	0.65	2	29	23.5	77	247	14.8	65	1734	0.43	8.5
16.5mm	0.65	2.5	37	24.5	80	275	16.5	73	1885	0.47	8.8
16.5mm	0.65	3	44	25.5	84	303	18.2	80	2042	0.50	8.9
16.5mm	0.65	4	56	28.0	92	350	21.0	92	2462	0.61	8.5
17.8mm	0.70	2	29	24.0	79	308	18.5	81	1809	0.45	10.2
17.8mm	0.70	2.5	37	25.5	84	333	20.0	88	2042	0.50	9.8
17.8mm	0.70	3	44	26.0	85	343	20.6	91	2123	0.52	9.7
17.8mm	0.70	4	56	29.0	95	437	26.2	115	2641	0.65	9.9
19.1mm	0.75	2	29	25.0	82	345	20.7	91	1963	0.48	10.5
19.1mm	0.75	2.5	37	26.0	85	275	16.5	73	2123	0.52	7.8
19.1mm	0.75	3	44	26.5	87	378	22.7	100	2205	0.54	10.3
19.1mm	0.75	4	56	30.0	98	437	26.2	115	2826	0.70	9.3
20.3mm	0.80	2.5	37	27.0	89	375	22.5	99	2289	0.57	9.8
20.3mm	0.80	3	44	28.0	92	375	22.5	99	2462	0.61	9.1
20.3mm	0.80	4	56	32.0	105	460	27.6	122	3215	0.79	8.6

商品规格

Attribute name	Attribute value
Body Angle	Medium Body Angle (23 ° to 30 °)
Water Input	2"
Circle	Full & Part
Minimum Required Pressure	29 psi (2 bar)
Maximum Working Pressure	73 psi (5 bar)
Minimum Required Water Flow	185 l/min
Maximum Water Flow	550 l/min
Minimum Shooting Range	21 - 25 m
Maximum Shooting Range	30 - 40 m
Nozzles	14, 16, 18, 20, 22, 24 mm
