Aytok Minithings Plastic Disc Filter
Aytok MPD-MPE filters are used effectively to meet the filtering needs of water required for low-capacity usage areas. Due to its small size, it is used effectively in many areas. It is widely used in fields such as garden irrigation systems, fertilization systems, and small-scale cooling water filtration.
General Characteristic
Body Material : PP
Cartridge Material: Screen Cartridge (SS 304+PP )
Maximum Working Pressure : 8 Bar (116 PSI)
Maximum Working Temperature: 60 °C/ 140 °F
Filtration Degree: 130 micron
CODE |
D |
M |
T |
D1 |
H |
K |
FLOW |
FILTRATION AREA |
WEIGHT |
inch |
mm |
m³/h |
cm² |
kg |
MPE3/4 |
3/4 |
|
1/2 |
68 |
190 |
160 |
5 |
165 |
0,3 |
MPE10 |
1 |
|
1/2 |
68 |
190 |
160 |
6 |
165 |
0,3 |
MPE10S |
1 |
|
1/2 |
96 |
230 |
220 |
10 |
300 |
1 |
MPE15 |
1½ |
|
1/2 |
96 |
230 |
220 |
15 |
300 |
0,75 |
MPE15S |
1½ |
1/4 |
1/2 |
120 |
280 |
270 |
20 |
515 |
1,2 |
MPE20 |
2 |
1/4 |
1/2 |
120 |
280 |
270 |
25 |
515 |
1,2 |
Filter Cleaning
The pressure difference between the inlet and outlet is observed manually from the manometers. If the pressure difference increases, the water flow is cut off and the system is stopped. Then remove the cover and take out the cartridge. For screen filter, the screen can be directly cleaned with pressurized water and reassemblied. For disc filter, loosen the the disc cartridge screw and clean the disc with pressurized water, then the filter can be reassemblied.
